Part 5 of “The Inference Wall”. A step back onto the series’ rig, with a dense companion alongside: Qwen3.5-4B and Qwen2.5-7B on a single NVIDIA A10G (23 GB), served under vLLM.

Manas Pathak · September 25, 2026

The Inference Wall · All posts · Part 5

An inference server keeps a KV cache for every request in flight, the keys and values it has computed so far, and the GPU memory holding it is finite. Under enough load, more requests want to run than that memory can hold. The server has two options. It can refuse to start new work until room frees up. That is admission control: a request waits in a queue rather than running with nowhere to store its keys and values. Or it can start the work optimistically and, when the cache later fills mid-generation, evict a running request: throw away its cached state, hand the blocks to someone else, and reconstruct the evicted request’s state later. The naive strategy is to admit everything, run out of memory mid-decode, and crash; admission control and eviction are the two ways a server avoids it.

Every modern engine picks a point on that spectrum, and the point it picks is a real design decision with observable consequences. This post is about watching one server, vLLM, actually degrade under a starved cache. I flood it until the cache is the binding constraint and read the counter that says what happened. The short version is that vLLM lands on the evict end of the spectrum, its eviction backstop fires on every workload I tried rather than only the starved ones, and the cost is latency, not a crash. Getting to that answer required noticing that the most obvious way to measure it, grepping the server log, returns zero on every run because the log line cannot print in this version.

The two ends of the spectrum, across engines

Before the measurements, it helps to see that “admit or evict” is not a vLLM quirk but the axis every serving engine sorts itself along, and engines fall into two groups.

Pure admission control engines never evict a running request. Hugging Face’s Text Generation Inference profiles the GPU at startup to learn how many tokens of KV it can physically hold, then enforces a strict token budget (max_batch_total_tokens) in its Rust router: a request joins the running batch only if its tokens fit, and otherwise waits in the client-facing queue. A request that has started decoding is never paused to free its memory; TGI’s waiting-vs-running knobs only ever pause decode briefly to let a queued request run its prefill and join, never to reclaim a running request’s blocks. TensorRT-LLM’s default capacity policy, GUARANTEED_NO_EVICT, is the same shape drawn conservatively: it admits a request only if it can reserve enough blocks for the request’s entire declared output length up front, so once running, a request is guaranteed its slot to completion.

Evict-capable engines admit optimistically and pull work back under pressure. vLLM admits requests without reserving room for their eventual output, and when the pool runs dry mid-decode it preempts a running request. SGLang does the same in two stages: it first evicts unreferenced cached prefixes from its radix tree, and if that is not enough, retract_decode pulls running requests out of the batch and back to the queue. TensorRT-LLM will behave this way too, but only if you opt into it by setting the capacity policy to MAX_UTILIZATION instead of the default.

Engine Default under KV exhaustion Mechanism Evicts a running request?
TGI (Hugging Face) Cap admission by token budget max_batch_total_tokens, profiled at warmup Never (queues at the router)
TensorRT-LLM (default) Reserve full output up front GUARANTEED_NO_EVICT Never under default
vLLM Preempt and recompute RECOMPUTE (V1 default; host-swap dropped in V1) Yes
SGLang Evict prefixes, then retract radix-cache LRU eviction, then retract_decode Yes
TensorRT-LLM (MAX_UTILIZATION) Pack aggressively, evict on demand opt-in capacity_scheduler_policy Yes

Two clusters: admit-only (TGI, TRT-LLM default) and evict-capable (vLLM, SGLang, TRT-LLM opt-in). The rest of this post is about what “evict-capable” actually looks like when you make it happen, using vLLM as the specimen because it is the one where eviction is on by default and instrumented with a counter.

Two doormen at two clubs. On the left, a strict bouncer at a velvet rope counts the seats inside and turns people away at the door, letting a queue form outside but never touching anyone already seated. On the right, an easygoing bouncer waves the whole crowd straight in, and when the room overflows he taps a few seated guests on the shoulder and walks them back out to the end of the line, telling them they will have to start over when they get back in

What vLLM does when the cache fills

vLLM’s recovery mode is called RECOMPUTE, and in the V1 engine it is the only one. The older path that swapped a preempted request’s KV cache out to host memory was dropped in V1. So preemption in today’s vLLM means one thing, and the source spells it out. When the scheduler preempts a request, it frees that request’s KV blocks back to the pool and resets its progress counter to zero, then puts it back on the waiting queue. On resume, the request re-runs its prefill from the beginning: every token it had already processed is computed again. No state is saved, so the recompute is the recovery.

The reason preemption is possible at all, the reason vLLM can find itself over-committed, is a single deliberate scheduling choice: admission reserves cache for the prompt only, never for the output. When a request is admitted, the scheduler allocates blocks for the tokens it needs to process right now, which at admission time is just the prompt. It does not set aside room for the hundreds of tokens the request will generate. That is what lets vLLM pack the GPU so densely, and it is also exactly why a batch that fit comfortably at admission can outgrow the pool a hundred decode steps later, when every admitted request has grown its KV by a hundred tokens and collectively they no longer fit. When an active decode step needs one more block and the free pool is empty, the scheduler preempts. Admit for the prompt, grow through decode, evict when growth outruns the pool.

That mechanism makes a prediction about when preemption should be worst: it should peak when admission is cheap but decode growth is large. Short prompts let many requests through the admission gate cheaply; long outputs then grow all of them until the pool goes dry. Hold that prediction; the positive control below is built to test it.

Preemption count across five arms

I flooded vLLM with 200 concurrent requests at unbounded request rate, so the queue is always full and the cache is always the binding constraint, across two models and a range of cache sizes, and counted preemptions. The counter is vllm:num_preemptions_total, read from the server’s Prometheus endpoint before and after each flood; the sidebar explains why I read it there and not from the server log.

Reading the table: each arm is one server configuration I flooded. The cache column is its KV pool size, either natural (the pool vLLM sizes itself from the GPU’s free memory) or tight (a pool I capped by hand with --num-gpu-blocks-override to force pressure); the Nx is the max concurrency that pool allows, how many requests of this workload’s shape can hold their KV at once. The workload column is prompt length / output length in tokens (in/out), and fixed means every request uses those exact lengths while variable draws each length from a range around them.

Arm Model / attention Cache (max concurrency) Workload (in/out) Preemptions
Roomy 4B 4B, hybrid natural, 83.7x 1024/512 fixed 17
7B natural, fixed 7B, dense natural, 45.2x 1024/512 fixed 60
7B natural, variable 7B, dense natural, 45.2x 512/512 variable 101
4B tight 4B, hybrid 40-block, 5.7x 512/512 variable 41
7B tight 7B, dense 300-block, 2.3x 512/512 variable 173

Every arm preempts. Not just the deliberately starved ones. Even the roomiest cache, a 4B model with enough KV to seat 83 concurrent requests, preempted 17 times. Preemption is not a pathological-only event you have to engineer; a flood at unbounded rate transiently over-commits even when the average headroom looks generous.

The counts also move exactly the way the mechanism says they should. Squeeze the pool and the recompute path works harder: the dense 7B model under the same variable workload preempts 101 times with its natural cache and 173 times when I cap the cache to seat barely two requests. Adding output-length variance does the same. The same 7B model with the same natural cache preempts 60 times under fixed-length outputs and 101 under variable-length ones, because variance is what lets an admitted request outgrow the batch the scheduler had sized for it, which is the preemption trigger.

The positive control isolates the mechanism. On a single fixed tight-cache server, varying only the shape of the workload:

Workload in / out Admission vs. decode growth Preemptions
Cheap admit, huge growth 64 / 2000 many short prompts admitted, each grows 2000 tokens 205
Balanced 512 / 512 admission cost ≈ final footprint 36
Expensive admit, tiny growth 2000 / 64 long prompts gate the batch small at entry 19

This is the prompt-only admission rule made visible. Short prompts with long outputs are the worst case by a wide margin, 205 preemptions, because admission waves them all in and decode grows them all past the pool. Reverse it, long prompts and short outputs, and admission itself holds the running set small, leaving little growth to preempt over. The balanced 512/512 case still preempts 36 times and the long-prompt case 19: because admission never reserves for output, a burst of arrivals can transiently over-commit under almost any shape.

Two regimes: onset transient vs. steady-state churn

Counting total preemptions tells you how much but not when, and the when turns out to separate the roomy case from the tight case into two genuinely different behaviors. Sampling the metrics every three seconds through a flood draws the picture.

On the roomy 4B cache, preemptions arrive in two bursts at the start and then stop cold. The count climbs from 0 to 11 in the opening seconds as the running set overshoots to 104 requests at flood onset, ticks up to 17 as the queue drains into steady state, and then holds flat at 17 for the entire rest of the run while the running set sits steady around 97. The preemption here is a load-onset rebalancing transient: the scheduler over-commits in the first moments of the flood, sheds a few requests to recover, and once it settles it never preempts again.

On the tight 7B cache, the count climbs monotonically the whole run (2, 6, 12, 25, 40, on up to 181) while the running set stays pinned at three to seven requests. There is no settling: the cache is small enough that the server is permanently over-committed relative to demand, so it evicts and recomputes continuously as a steady-state cost of operating past its comfortable capacity. Same counter, same mechanism, two different regimes: a transient you pay once at load onset, and a churn you pay every second you run the cache too tight.

What preemption costs

Nothing crashed. Across every arm, all 200 requests completed. The eviction backstop engages when the naive server would have run out of memory and keeps the server up; the recompute work it creates does not disappear, it turns into latency.

The cost lands as the cache tightens, and it lands hard. Median time-to-first-token climbs from about 12 seconds on the dense model with its natural cache, to 2.7 minutes when the cache is capped tight on the hybrid model, to 5.7 minutes on the tightest dense arm. The 99th-percentile end-to-end latency on that tightest arm is 12.9 minutes for a request that would complete in seconds on an unloaded server. That is recompute work plus queueing, not a crash, but for an interactive workload it is indistinguishable from an outage.

One honest limit on what I could measure. vLLM’s token counters cannot quantify the recompute cost directly. The natural instinct is to look for wasted work, total prompt tokens processed minus the tokens actually requested, but that number comes back as exactly zero on every arm, even ones that preempted 181 times. It is not that recompute is free; it is that the counter is structurally blind to it. vLLM’s prompt-token counter sums the logical prompt lengths, which don’t change when a request is re-prefilled, and its one “recomputed tokens” counter tracks a narrow prefix-cache optimization that stays at zero when there is no prefix reuse. No counter in this version accumulates the physical re-prefill work that preemption causes. So the recompute cost is real (the source confirms every preempted request re-runs its prefill from scratch), but it is visible only indirectly, as the inflated latency above and depressed throughput, never as a clean “percent of compute wasted” figure. I would rather say that plainly than invent a number.

If you run vLLM, you are on the evict-capable end by default. Size the KV cache around the concurrency you actually need: under-provision it and the server won’t fall over, it will preempt, recompute, and inflate tail latency into the minutes while every request still eventually succeeds. A starved cache doesn’t crash and doesn’t page you; it makes everything slow. If your workload cannot tolerate that tail, either give the cache more room or pick an engine that sits on the admission-control end, where the backpressure shows up as an explicit queue rather than as latency.

The obvious way to count preemptions in vLLM is to grep the server log for the line it prints when it preempts, a clause that reads Preemptions: N. In the version I ran, that line reports zero preemptions on every arm, even on arms that preempt hundreds of times. It is a false negative, and it comes from a mechanical bug in the logging path.

That log clause is dead code in the version I ran. The logging routine resets its running statistics, including the preemption count, to zero before it reaches the check that decides whether to print the Preemptions: clause. The check is if preemptions > 0, and by the time it runs, the count has already been zeroed, so the branch is never taken. Unlike the throughput stats, which are copied aside before the reset, the preemption count is simply lost. The clause can never print. Every “zero” it gave me was a false negative from a line of code that cannot fire.

The Prometheus counter vllm:num_preemptions_total on the /metrics endpoint is incremented at the source and survives the reset. Every number in this post is the delta of that counter across a flood. The positive control caught the bug: forcing preemption with a short-prompt/long-output workload and watching the log counter still read zero while the metrics counter climbed to 205 is what showed the log line, not vLLM’s behavior, was the problem.

Reproduce

All runs are vLLM 0.18.0 on a single NVIDIA A10G (23 GB), --dtype float16, --max-model-len 2048, --max-num-seqs 256, --gpu-memory-utilization 0.9, driven by vllm bench serve with --dataset-name random --request-rate inf --ignore-eos --num-prompts 200 --seed 0. Fixed-length arms use --random-range-ratio 0.0; variable arms use 0.9. Tight caches are set with --num-gpu-blocks-override (40 blocks for the hybrid 4B, 300 for the dense 7B). Models are Qwen/Qwen2.5-7B-Instruct (dense) and Qwen/Qwen3.5-4B (hybrid attention). Preemptions are the delta of vllm:num_preemptions_total scraped from curl localhost:8000/metrics before and after each flood, never the server-log clause, which cannot print in this version. The five-arm sweep (run_counter_remeasure.sh), the positive control (run_preempt_positive_control.sh), and the recompute cross-check with its three-second metric timelines (run_recompute_crosscheck.sh) are in experiments/05-cache-starvation/; the raw remeasure.log, pc_driver.out, crosscheck.log, and per-regime cc_timeline_*.log files they produced are in benchmarks/05-cache-starvation/. Single A10G; absolute numbers are rig-specific, the shape and the mechanism are not.
